Harrington LB Heavy Duty Lever Hoists

Harrington LB Heavy Duty Lever Hoists The LB Series of lever hoists offers a low headroom, compact design that is perfect for use in tight quarters. Regarded as the best lever hoist in the industry, the LB is recommended for use in heavy-duty construction work, mining, manufacturing, shipbuilding, and day-to-day maintenance and repair. CAPACITY 3/4 – 3 Ton COMPLIANCE ANSI/ASME B30.21, “Safety Standard—Manually Lever Operated Hoists.” ANSI/ASME HST—3M, “Performance Standard for Manually Lever Operated Chain Hoists.” BODY Rugged, high-impact, all-steel construction weighs less than comparable aluminum models Compact and lightweight Open design for easy inspection and cleaning without dismantling the unit HOOKS Forged, heat-treated alloy steel hooks open gradually without fracturing under excessive load Top and bottom hooks have heavy-duty hook latch Top and bottom hooks rotate 360 degrees OPERATION Rubber grip handle for non-slip operation Operate in close quarters with short handle and 15-degree recovery stroke Patented spring-loaded freewheel mechanism for easy adjustment of the load chain and protection against accidental freewheeling under load GEARS Highly durable, split-load double reduction gears Induction heat-treated and case-hardened Enclosed to protect from dust and moisture LOAD CHAIN Nickel-plated for corrosion resistance Grade 100 heat-treated Standard lift: 5′, 10′, 15′ or 20′ BRAKE Weston-style load brake with four braking surfaces, two brake pads and two brake pawls for added safety The totally enclosed brake mechanism protects from dirt and moisture Owners Manual
